7 Other Functions
7 - 17
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
7-1-36 Pulse Train Input EA Monitor [d133]
Use this function to display the pulse train command or feedback value that is input to the pulse train
input terminal EA in units of percentage as 100% of the 1st/2nd Maximum Frequency (A004/A204).
This function is enabled independently of the Pulse Train Input EA Selection (P003) setting.
In the Pulse Train Frequency Scale (P055), set the pulse train command value relative to the maximum
frequency.
Parameter
No.
Function name
Data
Default
data
Unit
d133
Pulse Train Input EA Monitor
0.00 to 100.00
−
%
Related functions
P003, P055
7-1-37 PID Deviation [d153]
Use this function to display the deviation in PID control when the PID Selection (A071) is set to 01
(Enabled) or 02 (Reverse output enabled). The monitor value is displayed in units of percentage as
100% of the 1st/2nd Maximum Frequency (A004/A204).
It can be converted by setting the PID Scale (A075) as follows.
d153 = PID deviation value × PID Scale (A075)
Parameter
No.
Function name
Data
Default
data
Unit
d153
PID Deviation
−9999.00 to 9999.00
*1
−
%
Related functions
A071, A004, A204, A075
*1. The digit shift display mode can be used.
7-1-38 PID Output Monitor [d155]
Use this function to display the operation output of PID control operation when the PID Selection (A071)
is set to 01 (Enabled) or 02 (Reverse output enabled). The monitor value is displayed in units of per-
centage as 100% of the 1st/2nd Maximum Frequency (A004/A204).
Parameter
No.
Function name
Data
Default
data
Unit
d155
PID Output Monitor
−100.00 to 100.00
−
%
Related functions
A071, A004, A204
7
7-1 Monitor Mode
7-1-36 Pulse Train Input EA Monitor [d133]
