7-5-12 PID Function
Use this function to control the flow rate, air volume, pressure, and other processes. To use this func-
tion, set A071 to 01 (Enabled) or 02 (Enabled: Reverse output enabled).
The PID function can be disabled during PID operation via external signal input.
To use this function, set one of the Multi-function Input 1 to 7 Selection (C001 to C007) to 23 (PID: PID
disabled). This causes the PID function to be disabled while the terminal PID is ON and the inverter
generates an output according to the frequency reference.
You can also use this function to limit the PID output with reference to the target value. Set the
upper/lower limit value in the PID Variable Range Limit (A078) as a percentage of the maximum fre-
quency.
Because the PID output is a frequency reference for the inverter, the base frequency, maximum fre-
quency, frequency limit settings are enabled. For details on these functions, refer to 5-3-3 Base Fre-
quency and Maximum Frequency of Motor on page 5-20, 5-5-3 Frequency Limit on page 5-30, and PID
Variable Range Limit (A078).
00:
Analog current (Terminal OI)
*1
4 to 20 mA
01:
Analog voltage (Terminal O)
*1
0 to 10 V
02: Modbus communication
03: Pulse train frequency
10:
Operation function output
*1
