7-8-3 Electronic Thermal Warning
Use this function to output a warning signal before the motor electronic thermal function executes an
overload protection. In C061, set the warning level.
Set the Multi-function Output 11/12 Selection (C021/C022) or Multi-function Relay Output (AL1, AL2)
Function Selection (C026) to 13 (THM).
Parameter
No.
Function name
Data
Default
data
Unit
C061
Electronic Thermal Warning Level
0.
Electric thermal warning disabled
90.
%
1. to 100.
*1
Set the output level of the thermal
warning signal.
Multi-function Output 11/12
13: THM (Electronic thermal
warning)
C021, C022,
C026
Selection
Multi-function Relay Output (AL1,
−
−
AL2) Function Selection
*1. Set this in units of percentage as 100% of the overload trip level (E05).
7
7-8 Functions Related to Protection, Warning, and Various Output Signals
7-8-3 Electronic Thermal Warning
