4-3 Extended Function Mode
In the extended function mode, inverter parameters are categorized in six groups: A, b, C, H, P, and U.
This section provides the parameter list for each group.
Note that the parameters displayed on the Digital Operator vary with the setting in the Display Selection
(b037). To display all parameters, set this parameter to 00 (Complete display).
If the data exceeds the display digits, the Digital Operator displays the upper digits for monitoring and
the lower digits for setting. To monitor digits that are not displayed, use the digit shift display mode. For
details, refer to Digit Shift Display Mode on page 3-11.
Precautions for Correct Use
You can change the parameter display on the Digital Operator by the Display Selection (b037).
For details, refer to 5-1-1 Display Selection on page 5-3.
Additional Information
•
You can set the initial screen displayed after turning on the power supply by the Initial Screen
Selection (b038). For details, refer to 7-6-5 Initial Screen Selection (Initial Screen after
Power-on) on page 7-56.
•
You can display only the parameters registered as user parameters. It is also possible to
automatically register changed parameters, or directly set specific parameters. For details,
refer to 7-6-11 User Parameter Automatic Setting Function on page 7-60.
To Next Page
