12 Options
12 - 2
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
12-1 Overview of Optional Equipment
This section provides an overview of the optional equipment available with the 3G3MX2-EV2 Series
Inverter. For details and selection, refer to the inverter datasheet
12-1-1 Part Names and Descriptions
Use these reactors to suppress harmonics generated from the inverter.
The AC reactor is used when the power supply voltage unbalance factor is 3% or more, the inverter is
much smaller than the supply, or unstable power supply voltage is present.
The DC/AC reactor also has an effect of improving the power factor by reducing harmonics and total
reactive power consumption.
For details, refer to 2-3-4 Wiring for Main Circuit Terminals on page 2-17 and Harmonic Current Mea-
sures and DC/AC Reactor Wiring (+1, P/2) on page 2-28.
Use this filter to reduce the conductive disturbance generated by inverter conmutation voltages and the
problems caused by long motor cables.
For details, refer to Installing output noise filter on page 2-32.
Use this filter to reduce the radiated noise generated in the inverter and emitted from the power-supply
line side and motor side wires.
For details, refer to Measures against radio noise on page 2-33.
12-1 Overview of Optional Equipment
DC Reactor (Model: 3G3AX-RC)/AC Reactor
(Model: 3G3AX-RAI)
Output AC Reactor (Model: AX-RAO)
Radio Noise Filter chokes (Model: AX-FER)
