PIAGGIO Liberty 125 User Manual

Specification Desc./Quantity
Front tyre pressure 2 bar
Rear tyre pressure 2.2 bar
Rear tyre pressure (rider and luggage) 2.5 bar
Secondary air
In order to reduce polluting emissions, the vehicle
is furnished with a catalytic converter in the muf-
fler.
To favour the catalytic process, an extra amount
of oxygen is added via a secondary air system
(SAS).
This system allows more oxygen to be added to
the unburned gases before they reach the con-
verter, thus improving the action of the catalytic
converter.
The air enters the exhaust duct from the head, and
is purified by a black filter.
The system is fitted with a control valve that disa-
bles operation while decelerating to avoid unwan-
ted noise.
To ensure the best functioning of the SAS system,
every 12,000 km the scooter should be taken to an
Authorised Piaggio Service Centre to have the
filter cleaned (Scheduled maintenance operations
section).
The filter sponge should be cleaned with water and
mild soap, then it should be dried with a cloth and
slight blows of compressed air.
CAUTION
CONTACT AN AUTHORISED PIAGGIO SERVICE CENTRE
TO CARRY OUT THESE OPERATIONS.
Carburettor
125cc Version
Liberty 125 - 200 4tempi Characteristics
CHAR - 11

PIAGGIO Liberty 125 Specifications

General

Displacement	124 cc
Fuel System	Electronic Injection
Front Suspension	Hydraulic telescopic fork
Rear Brake	140 mm drum
Front Tire	90/80 - 16"
Rear Tire	100/80 - 14"
Wheelbase	1, 340 mm
Length	1, 945 mm
Width	690 mm
Seat Height	790 mm
Engine Type	Single cylinder, 4-stroke
Torque	10.4 Nm @ 8, 000 rpm
Cooling System	Air cooled
Transmission	CVT
Rear Suspension	Single shock absorber
Front Brake	240 mm disc
Fuel Tank Capacity	6 liters
Weight	124 kg
