Brake hoses
BRAKE HOSES
Code
Action Duration
1 002007 Front brake shoes/pads - Remov.
and Refitt
2 002039 Front brake line - Replacement
3 002021 Front brake hose - Remov. and Re-
fitt.
4 002047 Front brake fluid and system bleed-
ing plug - Repl.
Liberty 125 - 200 4tempi Time
TIME - 203
