Footrest
• Remove the countershield
• Remove the frame central cover
• Unscrew the screws that secure the passenger
footrest and remove it
• Unscrew the footrest stop screw and remove the
tab
• Remove the 2 external rubber caps of the screws
securing the footrest and unscrew them
• Pull the footrest up being careful of the lower
hooks
See also
Knee-guard
Frame central cover
License plate holder
• Remove the saddle compartment cover
• Unscrew the 2 screws securing it to the frame,
then remove the license plate housing
See also
Frame central cover
Chassis Liberty 125 - 200 4tempi
CHAS - 160

PIAGGIO Liberty 125 Specifications

General

Displacement	124 cc
Fuel System	Electronic Injection
Front Suspension	Hydraulic telescopic fork
Rear Brake	140 mm drum
Front Tire	90/80 - 16"
Rear Tire	100/80 - 14"
Wheelbase	1, 340 mm
Length	1, 945 mm
Width	690 mm
Seat Height	790 mm
Engine Type	Single cylinder, 4-stroke
Torque	10.4 Nm @ 8, 000 rpm
Cooling System	Air cooled
Transmission	CVT
Rear Suspension	Single shock absorber
Front Brake	240 mm disc
Fuel Tank Capacity	6 liters
Weight	124 kg
