Electrical system
Battery
BATTERY
Possible Cause Operation
Battery The battery is the electrical device in the system that requires
the most frequent inspections and thorough maintenance. If the
vehicle is not used for some time (1 month or more) the battery
needs to be recharged periodically. The battery runs down
completely in the course of 5 ÷ 6 months. If the battery is fitted
on a motorcycle, be careful not to invert the connections, keep-
ing in mind that the black ground wire is connected to the
negative terminal while the red wire is connected to the terminal
marked+. Follow the instructions in the ELECTRICAL SYSTEM
chapter for the recharging of the batteries.
Turn signal lights malfunction
TURN INDICATOR NOT WORKING
Possible Cause Operation
Electronic ignition device failure With the key switch set to "ON" jump the contacts 1 (Blue-
Black) and 5 (Orange) on the control unit connector.
If by operating the turn indicator control the lights are not stead-
ily on, replace the control unit; otherwise, check the cable
harness and the switch.
Steering and suspensions
Heavy steering
STEERING HARDENING
Possible Cause
Operation
Steering hardening Check the tightening of the top and bottom ring nuts. If irregu-
larities continue in turning the steering even after making the
above adjustments, check the seats in which the ball bearings
rotate: if they are recessed or if the balls are squashed, replace
them.
Excessive steering play
EXCESSIVE STEERING CLEARANCE
Possible Cause
Operation
Excessive steering clearance Check the tightening of the top ring nut. If irregularities continue
in turning the steering even after making the above adjust-
ments, check the seats in which the ball bearings rotate: re-
place if they are recessed.
Troubleshooting Liberty 125 - 200 4tempi
TROUBL - 38
