Air duct filter
- Unscrew the 2 fixing screws and slide off the filter.
- Clean with water and milid soap.
Removing the driven pulley shaft bearing
- Remove the clip from the inside of the cover.
- Use the specific tools to remove the bearing from
the crankcase.
CAUTION
USE AN APPROPRIATE REST SURFACE TO AVOID DAM-
AGING THE COVER PAINT.
Specific tooling
020376Y Adaptor handle
020375Y Adaptor 28 x 30 mm
Engine Liberty 125 - 200 4tempi
ENG - 66

PIAGGIO Liberty 125 Specifications

General

Displacement	124 cc
Fuel System	Electronic Injection
Front Suspension	Hydraulic telescopic fork
Rear Brake	140 mm drum
Front Tire	90/80 - 16"
Rear Tire	100/80 - 14"
Wheelbase	1, 340 mm
Length	1, 945 mm
Width	690 mm
Seat Height	790 mm
Engine Type	Single cylinder, 4-stroke
Torque	10.4 Nm @ 8, 000 rpm
Cooling System	Air cooled
Transmission	CVT
Rear Suspension	Single shock absorber
Front Brake	240 mm disc
Fuel Tank Capacity	6 liters
Weight	124 kg
