PIAGGIO Liberty 125 User Manual

VERSION 200
Specification Desc./Quantity
Minimum width 21±0.2 mm
Standard width 22±0.2 mm
Removing the driving pulley
Driving pulley removal
- With the appropriate tool placed into the internal slots, remove the nut with the built-in Belleville washer.
Appropriate tools:
Specific tooling
020442Y Pulley lock wrench
- Remove the entire start-up crown unit with the
torque limiter.
- Remove the fixed driving half-pulley together with
the O-ring and the steel washer touching the bush-
ing.
Engine Liberty 125 - 200 4tempi
ENG - 76

PIAGGIO Liberty 125 Specifications

General

Displacement	124 cc
Fuel System	Electronic Injection
Front Suspension	Hydraulic telescopic fork
Rear Brake	140 mm drum
Front Tire	90/80 - 16"
Rear Tire	100/80 - 14"
Wheelbase	1, 340 mm
Length	1, 945 mm
Width	690 mm
Seat Height	790 mm
Engine Type	Single cylinder, 4-stroke
Torque	10.4 Nm @ 8, 000 rpm
Cooling System	Air cooled
Transmission	CVT
Rear Suspension	Single shock absorber
Front Brake	240 mm disc
Fuel Tank Capacity	6 liters
Weight	124 kg
