Name Torque in Nm
Alternator flywheel nut 40 ÷ 44 Nm
Stator screws 3 ÷ 4
Pick-up screws 3 ÷ 4
Oil pump bulkhead screw 4 ÷ 5
Timing chain/oil pump compartment cover screws 4 ÷ 5 Nm
Oil decantation labyrinth sheet screws 7 ÷ 8
Oil pump crown screw 8 ÷ 10
Screws fixing oil pump to crankcase 5 ÷ 6
Oil pump coupling screws 7 ÷ 9 Nm
Oil sump screws 8 ÷ 10 Nm
Inlet manifold screw 7 ÷ 9
Carburettor/manifold clamp screw 1.2 ÷ 1.5 Nm
Screws fixing cables to starter motor 1.5 ÷ 2.5
Starter motor screws 11 ÷ 13
Transmission cover screws 11 ÷ 13 Nm
Crankcase cooling cover screw 2 ÷ 2.5
Nut locking clutch unit on pulley 55 ÷ 60 Nm
Crankshaft pulley nut 18 to 20 + 90° Nm
Driven pulley shaft nut 40 ÷ 44 Nm
Hub oil drainage screw 3 ÷ 5 Nm
Rear hub cap screws 24 ÷ 26 Nm
Wheel axle nut 115 ÷ 125
Crankcase half union screw 8 ÷ 10
Per assicurare una corretta coppia di bloccaggio lubrificare i dadi prima del montaggio.
* Montando dei nuovi prigionieri, l'operazione di serraggio dei dadi comprende l'effettuazione di 3 rotazioni di 90° dopo il primo
bloccaggio a 6÷7 Nm, pertanto: 6÷7 Nm + 90° + 90° + 90° a passaggi incrociati.
STEERING ASSEMBLY
Name
Torque in Nm
Upper steering ring nut 35 ÷ 40
Steering lower ring nut 12 ÷ 14
handlebar fixing screw 45 ÷ 55
FRAME ASSEMBLY
Name
Torque in Nm
Engine-swinging arm bolt 33 ÷ 41
Frame-swinging arm bolt 64 - 72
Shock absorber - chassis nut 20 ÷ 25
Shock absorber/engine pin 33 - 41 N.m
Rear wheel axle 104 ÷ 126
Stand bolt 20 ÷ 25
Front mudguard fixing screw 4 ÷ 6
FRONT SUSPENSION
Name
Torque in Nm
Fork bottom screw 20 ÷ 25
Front wheel axle 45 ÷ 50
Odometer drive screw 6 ÷ 7
FRONT BRAKE
Name
Torque in Nm
Brake fluid pump-hose fitting 20 ÷ 25
Brake fluid pipe-calliper fitting 20 ÷ 22
Calliper tightening screw 20 ÷ 25
Disc tightening screw (Apply LOCTITE 243 medium-strength
threadlocker)
8 ÷ 12 Nm
Oil bleeding valve 8 ÷ 12
Overhaul data
Liberty 125 - 200 4tempi Characteristics
CHAR - 13
