Electronic controls
ELECTRIC CONTROLS
Code
Action Duration
1 005039 Lights switch - Replacement
2 005006 Light or turning indicator switch - Re-
placement
3 005040 Horn button - Replacement
4 005003 Horn - Replacement
5 005041 Starter button - Replacement
6 005016 Key switch - Replacement
7 004096 Lock series - Replacement
8 005072 Immobilizer aerial - Replacement
Liberty 125 - 200 4tempi Time
TIME - 209
