Oil pump
OIL PUMP
Code
Action Duration
1 001051 Belt/Timing chain - Replacement
2 001125 Chain guide pads - Replacement
3 001042 Oil pump - Overhaul
4 001112 Oil pump - Replacement
5 001130 Oil sump - Replacement
6 001100 Oil seal clutch side - Replacement
7 001122 Oil pump chain - Replacement
Liberty 125 - 200 4tempi Time
TIME - 181
