Polaris ACE 900 2017 User Manual

6.2
9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
GENERAL INFORMATION
TORQUE SPECIFICATIONS -
TRANSMISSION
TRANSMISSION
ITEM
TORQUE
Transmission Fill / Drain
Plug
14 ft-lbs (19 Nm)
Engine / Transmission
Mounting Fasteners
Pre-Torque 5 ft-lbs (7
Nm)
45 ft-lbs (61 Nm)
Transmission Isolator
Fastener
40 ft-lbs (54 Nm)
Transmission Isolator
Mount to Frame
Fasteners
22 ft-lbs (30 Nm)
Shift Lever Mount
Fasteners
Torque Till Seated
Shift Cable Fasteners 13 ft-lbs (18 Nm)
Shifter Cable
Jam Nut
Front
18 ft-lb (24 Nm)
Rear
13 ft-lbs (18 Nm)
Bearing Cover Retaining
Screws
10 ft-lb (14 Nm)
Snorkel Locking Screw 10 ft-lb (14 Nm)
Transmission Case Bolts 20 ft-lbs (27 Nm)
Sector Gear Cover Bolts 12 ft-lb (16 Nm)
Bell Crank Nut 18 ft-lb (24 Nm)
SPECIAL TOOLS - TRANSMISSION
SPECIAL TOOLS
PART NUMBER TOOL DESCRIPTION
PA-50231 Snorkel Tool
2871698
(Part of 2871702 Kit)
Rear Output Seal Driver
2871699
(Part of 2871702 Kit)
Rear Driveshaft Seal
Guide
2871282
Bearing Seal Driver
(50 mm)
PU-50566 Transmission Nut Socket
PU-50658
Clutch Center Distance
Tool
Bosch Automotive Service Solutions 1-800-345-
2233 or https://polaris.service-solutions.com
LUBRICATION SPECIFICATIONS -
TRANSMISSION
FLUID CAPACITY
Recommended Transmission Lubricant:
AGL Synthetic Gearcase Lubricant
44 oz. (1300 ml)
TRANSMISSION
