WALKER EVANS 1.5” REAR SHOCK INFORMATION

ITEM

SPECIFICATION

Shock Travel

7.764

Extended Length 23.264

IFP Depth 3.375

Nitrogen Pressure

200 psi (1379 kPa) +/- 10%

Gas Shock Oil

10 wt WER

Compression Adjustment (factory) 6 clicks CCW from full soft setting

Spring Adjustment Setting

COMPRESSION REBOUND

ADJUSTER

COMPRESSION

ADJUSTER

REBOUND

SHAFT BLEED PISTON BLEED

1.30 x .008 .875 x .090 1.10 x .025 .700 x .010 .082 .067

.900 x .012 .800 x .010 1.10 x .012

1.25 x .008 .900 x .010 1.00 x .025

1.00 x .010 1.00 x 0.10 .625 x .065

.900 x .010 1.10 x .010

.800 x .010 1.25 x .010

.700 x .010

.875 x .090
