10.6
9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
DOORS
q
Door Panel
i
Hinge Pin
w
Latch Bracket
o
E-clip
e
Bolster
a
Door Hinge Screws
8 ft-lbs (11 Nm)
r
Door Frame
s
Door Panel Screws
22 In-lbs (2 Nm)
t
Latch
d
Door Latch Screws
8 ft-lbs (11 Nm)
y
Latch Release
f
Latch Bracket Screws
12 ft-lbs (16 Nm)
u
Door Hinge
BODY / FRAME
