Page #219 background imageLoading...
Page #219 background image
Under Windows or LDAP authentication, a user logs in to the same user account by using
multiple login user names, and these multiple login names are registered in the Address Book
as separate users.
The following operations are exempt from print volume limitation:
Printing from an operating system that does not support the current authentication method.
Specifying Limitations for Print Volume
1. Log in as the machine administrator from Web Image Monitor.
2. Point to [Device Management], and then click [Configuration].
3. Click [Print Volume Use Limitation] under "Device Settings".
4. Select [Stop Job] or [Finish Job and Limit] in the "Machine Action When Limit is Reached"
list.
If you do not want to limit print volume, select [Allow Continue Use].
5. For each print condition, enter a per-page unit count between "0" and "200" in [Print
Volume Use Limitation: Unit Count Setting].
If you specify "0" for a print condition, no volume restriction is applied to jobs matching that
condition.
6. Click [OK].
7. Log out.
1. Log in as the machine administrator from the control panel.
2. Specify the printer behavior when printing limit is reached.
[System Settings] [Administrator
Tools]
[Machine
action when limit is reached]
[Stop Job]
or [Finish Job and Limit] [OK]
If you do not want to limit print volume, select [Allow Continue Use].
3. Enter a per-page unit count.
[Print Volume Use Limitation: Unit Count Setting] Select
print condition
Use the number keys
to enter a per-page unit count between "0" and "200" [OK] [OK]
If you specify "0" for a print condition, no volume restriction is applied to jobs matching that
condition.
Managing Print Volume Per User
73

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh SP 4510dn and is the answer not in the manual?

Ricoh SP 4510dn Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLED
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)5 s
Print speed (black, normal quality, A4/US Letter)40 ppm
Printing colorsBlack
Maximum duty cycle150000 pages per month
Number of print cartridges1
Page description languagesPCL 5e, PCL 6
Total input capacity600 sheets
Maximum input capacity1600 sheets
Paper tray media typesPlain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight52 - 162 g/m²
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Multi-purpose tray media typesLetterhead
Maximum ISO A-series paper sizeA4
Wi-Fi-
Supported network protocols (IPv4)TCP/IP
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
Storage mediaHDD
Internal memory512 MB
Maximum internal memory1536 MB
Internal storage capacity320 GB
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)1110 W
Power consumption (printing)- W
Power consumption (PowerSave)1 W
Product colorGrey, White
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth392 mm
Width370 mm
Height306 mm
Weight14000 g
