Ricoh SP 4510dn User Manual

Importing Device Information
Import device information saved on an SD card.
Press the [Menu] key, and then select setting items using the [ ] or [ ] key.
1. Make sure the printer to which the settings will be imported is turned off.
2. Insert the SD card in the SD card slot.
For details about inserting the SD card and the slot location, see "Installing SD Card Options"
Operating Instructions.
3. Turn the printer on.
4. Log in from the control panel as an administrator with all privileges.
5. Select [Device Setting Informaiton] Press [OK]
6. Select [DevSettgInfo: Imp (MemDev)] Press [OK]
7. Select [Select Devc Setg Info File] Press [OK]
8. Select the file. Press [OK]
9. Select [Device Unique Information] Press [OK]
10. Select [Include] or [Exclude] Press [OK]
11. Select [Enter Encryption Key] Press [OK]
12. Select [Enter] Enter the encryption key that was specified when the file was exported.
Select [Accept]
13. Select [Import] [Import]
14. When the confirmation screen appears, press [Yes].
15. Make sure the message regarding that the exporting process being successfully
completed appears. Select [Exit]
The printer restarts.
16. Turn the printer off, and then remove the SD card.
1. Insert an SD card into the media slot at the front of the control panel.
For details about inserting the SD card and the slot location, see "Inserting/removing a memory
storage device" Operating Instructions.
2. Log in from the control panel as an administrator with all privileges.
Managing Device Information
211

Ricoh SP 4510dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6
Total input capacity	600 sheets
Maximum input capacity	1600 sheets
Paper tray media types	Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Letterhead
Maximum ISO A-series paper size	A4
Wi-Fi	-
Supported network protocols (IPv4)	TCP/IP
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Storage media	HDD
Internal memory	512 MB
Maximum internal memory	1536 MB
Internal storage capacity	320 GB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1110 W
Power consumption (printing)	- W
Power consumption (PowerSave)	1 W
Product color	Grey, White
Cables included	AC

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	306 mm
Weight	14000 g
