Data Types
The machine supports four different types of data that may be used to create an output page. These are:
text, graphics, images, and bar codes. The printed page can include any combination of these data
types.
Blocks of graphics, bar code or image data are presented as a single unit to the printer. The printer
enters the appropriate "Block" State (graphics block, image block, bar code block) to create the entire
data group for that block of data.
Page segments and Overlays are any combinations of text, graphics, bar codes and images. The printer
can store these segments and overlays for later use as the page is created.
Text
Presentation Text is the data type used to present lines of character information on a logical page.
The information to be presented is represented as a string of graphic character IDs and X'2B' control
sequences that are sent to the printer in the Write Text command (See "Write Text", IPDS Technical
Reference 2). The initial conditions governing the presentation of the data are established via control
parameters that are sent to the printer in the Logical Page Description command (See "Logical Page
Descriptor", IPDS Technical Reference 2).
The source architecture document for Text is Presentation Text Object Content Architecture Reference.
Image is the data type used to present rectangular arrays of raster data in an Image block area on a
page.
This data may have been created originally by a scanning process or generated by a computer
program. The machine supports the IM Image Function Set (See "IM Image Command Set", IPDS
Technical Reference 2). and the IO Image Function Set (See "IO Image Command Set", IPDS Technical
Reference 2).
The IM Image Function Set has a syntax and functional content that is based on AFPDS image arrays
and cells. The IO Image Function Set has a syntax and functional content based on the IOCA
architecture for image data (See Image Object Content Architecture Reference).
The raster data to be presented is represented as a sequence of scan lines 'm' lines deep by 'n' picture
elements (pixels) wide. In IO image data, there may be more than one bit per pixel if the image data is
grayscale encoded. The format of the data and the recording algorithms used to encode the image
array are sent to the printer as control parameters of the Write Image Control 2 command that prepares
the printer for processing image data. The data itself is sent in the Write Image 2 command.
Data Types
25

Ricoh SP 4510dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6
Total input capacity	600 sheets
Maximum input capacity	1600 sheets
Paper tray media types	Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Letterhead
Maximum ISO A-series paper size	A4
Wi-Fi	-
Supported network protocols (IPv4)	TCP/IP
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Storage media	HDD
Internal memory	512 MB
Maximum internal memory	1536 MB
Internal storage capacity	320 GB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1110 W
Power consumption (printing)	- W
Power consumption (PowerSave)	1 W
Product color	Grey, White
Cables included	AC

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	306 mm
Weight	14000 g
