RRL RT'07' Font Character Sets (GCSGID/FGID/FW)
• Valid combinations for the IBM Core Interchange Set are listed inpage 90 "Code Page" (IBM
Core Interchange Resident Scalable Font Set), and will be reported via XOARRL RT 07 RIDF 03.
•
Scalable Font Width (FW) will be reported as 0 to the host PSF. This indicates that any width/
scale-factor is valid.
• page 92 "Operating System/400 Terms" (GCSGID Subsets for IBM Core Interchange
Fonts) shows the subset GCSGIDs for each of the listed superset GCSGIDs in page 90
"Code Page" (IBM Core Interchange Resident Scalable Font Set). These subset GCSGIDs are
valid combinations for the associated superset GCSGIDs in the GCSGID/ FGID/FW, but will
not be added to the RRL 0703 response unless required by the host PSF's.
• Valid combinations for the IBM Coordinated Set are listed in page 97 "XOA-RRL Replies for Font
Character Sets" (Resident PSC Strategic Scalable Font Set 2) and will be reported via XOA-RRL RT
07 RIDF 03.
• Scalable Font Width (FW) will be reported as 0 to the host PSF. This indicates that any width/
scale-factor is valid.
• page 97 "XOA-RRL Replies for Font Character Sets" (GCSGID Subsets for the Strategic Font
Set 2) shows the subset GCSGIDs for each of the listed superset GCSGIDs in page 96 "IBM
Core Interchange Resident Scalable Font Set (IPDS only)" (Resident PSC Strategic Scalable
Font Set 2). These subset GCSGIDs are valid combination entries for the associated superset
GCSGIDs in the GCSGID/FGID/FW, but will not be added to the RRL 0703 response unless
required by the host PSF's.
• Valid combinations for the 4028 Compatibility Set require page 94 "Font and Code Page
Selection" (FGID/FW) and page 95 "Resident IPDS Fonts" (GCSGID), and will be reported via
XOA-RRL RT 07 RIDF 03.
• The FW's for these fonts are non-zero, because they represent fixed-width fonts.
• The Alternate FGIDs are valid values for GCSGID/FGID/FW combinations.
• Native Mode - These fonts (which are representing 4028 raster fonts) don't have a GCSGID
of their own, so the GCSGID used is from the associated Code Pages (CPGIDs).The
GCSGIDs are obtained by finding the Code Page(s) in page 95 "Resident IPDS Fonts" that
matches the Code Page(s) listed for a given FGID/FW entry in page 94 "Font and Code
Page Selection". The GCSGID for each of the Code Pages listed with an FGID is a valid
combination entry. Since these fonts don't have a superset GCSGID, there is no subset
condition. So each of these unique GCSGID/FGID/FW combinations will be added to the
XOA-RRL 0703 report to the host PSF.
• 4028 Emulation Mode - These fonts (which are representing 4028 raster fonts) don't have a
GCSGID of their own, so the GCSGID used is 0.
14
5. Code Page and Font Identification
86

Ricoh SP 4510dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6
Total input capacity	600 sheets
Maximum input capacity	1600 sheets
Paper tray media types	Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Letterhead
Maximum ISO A-series paper size	A4
Wi-Fi	-
Supported network protocols (IPv4)	TCP/IP
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Storage media	HDD
Internal memory	512 MB
Maximum internal memory	1536 MB
Internal storage capacity	320 GB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1110 W
Power consumption (printing)	- W
Power consumption (PowerSave)	1 W
Product color	Grey, White
Cables included	AC

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	306 mm
Weight	14000 g
