Offset Range Meaning Error Code
8-9 ORIENTATION OF IMAGE BLOCK X'0203..0
5'
X'0000' 0 degrees
X'2D00' 90 degrees
X'5A00' 180 degrees
X'8700' 270 degrees
10 COORDINATE REFERENCE SYSTEM X'0204..0
5'
X'00' Absolute I, absolute B
X'20' Absolute I, relative B
X'40' Relative I, absolute B
X'60' Relative I, relative B
X'A0' Page Xp, Yp
11-n Ignored
Image Output Control
This data structured field specifies the mapping option for the image object. It is an ELECTIVE data field
in the Write Image Control 2 command. If this field is omitted, the printer will use the following default
values:
Mapping option = X'30' (Position and Trim)
X, Y Offset = 0.
X, Y Extent = Image Presentation Space extent defined by the Image Data Descriptor structured field.
Offset Range Meaning Error Code
0-1 X'0010' -
X'xxxx'
LENGTH of Image Output Control X'0202..0
5'
2-3 X'A66B' Structured Field ID X'020B..
05'
IO Image Commands
137

Ricoh SP 4510dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6
Total input capacity	600 sheets
Maximum input capacity	1600 sheets
Paper tray media types	Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Letterhead
Maximum ISO A-series paper size	A4
Wi-Fi	-
Supported network protocols (IPv4)	TCP/IP
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Storage media	HDD
Internal memory	512 MB
Maximum internal memory	1536 MB
Internal storage capacity	320 GB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1110 W
Power consumption (printing)	- W
Power consumption (PowerSave)	1 W
Product color	Grey, White
Cables included	AC

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	306 mm
Weight	14000 g
