2.2 Functionality and properties of a SCALANCE X-300/X-400
SCALANCE X-300 / X-400
12 Configuration Manual, 10/2014, C79000-G8976-C187-22
Functionality and properties of a SCALANCE X-300/X-400
Integration of existing subnets with 10 Mbps and 100 Mbps
An IE switch automatically detects the following at its twisted pair ports:
● Send and receive wire pairs (autocrossover)
● Data rate (10 Mbps or 100 Mbps)
● Mode (full or half duplex)
This allows you to integrate subnets easily with IE switches over twisted pair.
Note
Even when using strai
ght cables, an illegal loop can occur in the Ethernet network, for
example by connecting two ports to an IE
switch. Such a loop can lead to network overload
Note
If an IE switch is connected to a partner device that does not opera
te in autonegotiation
mode, the port must be set permanently to the parameters of the partner.
If both ends of the connection are not set manually, the duplex mode will not be detected.
The half duplex mode is used and results in poorer performance and col
lisions.
These ports are particularly suitable for a high-performance connection between switches
and have the following properties:
● Automatic detection of the send and receive cable pairs (autocrossover)
● Data rates 10 Mbps, 100 Mbps, or 1000 Mbps
● Full duplex
Note
For data transmission at 1 Gbps, at least a Cat 5e twisted
-pair cable with 4 x 2 wires is
-wire cable (2 x 2 wires), a maximum data transmission rate of 100
