Configuration using Web Based Management and Command Line Interface
4.4 The Agent menu
SCALANCE X-300 / X-400
Configuration Manual, 10/2014, C79000-G8976-C187-22
85
Agent Configuration
Introduction
The "Agent Configuration" screen appears if you click the "Agent" folder icon. This screen
provides options for setting the IP address. You can specify whether a IE switch obtains the
IP address dynamically or you can assign a fixed address. You can also activate the options
for accessing the IE switch, such as TELNET or RMON.
IP configuration for the SCALANCE X414-3E
Here, you specify the IP configuration for the SCALANCE X414-3E. A distinction is made
between the switch ports (In-band column) and the Ethernet port of the switch CPU (Out-
band column).
sses of the CPU and the switch ports must belong to different subnets.
IP address of the SCALANCE X414-3E or the CPU module. If you change the IP address,
you should be automatically guided to the new address. If this does not happen, please enter
the new address in the Web browser manually.
Here, you enter the subnet mask of the SCALANCE X414-3E or the CPU module.
