Configuration using Web Based Management and Command Line Interface
4.4 The Agent menu
SCALANCE X-300 / X-400
Configuration Manual, 10/2014, C79000-G8976-C187-22
127
Syntax of the Command Line Interface
Table 4- 35 Agent PROFINET IO Configuration - CLI\AGENT\PNIOCONF>
Shows the current PROFINET IO configuration
Sets the PROFINET IO device name.
Clears a PROFINET IO fault state, if one exists
Management Access Control List
The Management Access Control List - an overview
On this page, you can increase the security of IE switch. To specify which host can access
the management of your IE switch using which IP address, configure the access rules for
individual hosts, subnets or all hosts.
The list of access rules presents this information clearly as shown in the example in the
following figure:
Figure 4-46 Management Access Control List - overview
-Band Port Enabled" (OBP) is only available for the SCALANCE X414.
Click on the ">>" and "<<" buttons to page backwards and forwards. On the second page,
instead of the ports, you will see any link aggregations that have been set up.
As soon as you have defined an access rule, all other access options are initially blocked if
they are not defined in this rule. If you want to allow access by other hosts or services, you
will need to define further access rules.
