PROFINET IO functionality
6.3 Access options over PROFINET IO
SCALANCE X-300 / X-400
Configuration Manual, 10/2014, C79000-G8976-C187-22
337
6.3
Access options over PROFINET IO
Note
The slot functions X
-300 table applies to all IE switches X-300 with the exception of the
following devices that have their own tables
:
•
X308-2M slot functions
•
Slot functions of the XR-324-12M
•
Slot functions of the X302-7EEC and X307-2EEC
•
Slot functions of the XR324-4M EEC
Slot functions X-300
The IE Switches X-300 have a subslot per switch port in slot 0.
Functions that cannot be assigned uniquely to one port are assigned to the device access
point (slot 0).
Slot 0 Subslot 1
• Alarms
• Data records (4.5)
Device Access Point (DAP)
• Interface connection
• C-PLUG
• Redundant power supply
Subslot 8001 - 8010
SCALANCE X304-2FE:
Subslot 8001 - 8006
SCALANCE X306-1LD FE:
Subslot 8001 - 8007
SCALANCE X320-1FE:
Subslot 8001 - 8021
SCALANCE X320-3LD:
Subslot 8001 - 8023
• Alarms (IEC)
• Data records (IEC)
Switch port 1 - 10 (or 1 - 6, 1 - 7, 1 - 21, 1 - 23)
• Alarm response
• Port state
