Siemens SCALANCE X-400 Configuration Manual

PROFINET IO functionality
6.4 Data record 0x802A (PDPortDataReal)
SCALANCE X-300 / X-400
346 Configuration Manual, 10/2014, C79000-G8976-C187-22
Status
Reserved
Bits 2-31
C-PLUG_status
Bits 0-1
0 Information regarding the C-PLUG of the network
component
0: C-PLUG inserted and OK
1: C-PLUG not inserted
2: C-PLUG inserted but not OK (incorrect type)
3: C-PLUG inserted but not OK (checksum error)
6.4
Data record 0x802A (PDPortDataReal)
Structure
typdef struct{
Word BlockType;
Word BlockLength;
Byte BlockVersionHigh;
Byte BlockVersionLow;
Word Padding;
Word SlotNumber;
Word SubslotNumber;
Byte LengthOwnPortID;
8 Byte OwnPortID;
Byte NumberOfPeers;
Word Padding;
Byte LengthPeerPortID;
8 Byte PeerPortID;
Byte LengthPeerChassisID;
8 Byte PeerChassisID;
Word Padding;
DWord LineDelay;
6 Byte PeerMACAddress;
Word Padding;
Word MAUType;
Word Padding;
DWord DomainBoundary;
DWord MulticastBoundary;
Word LinkState;
Word Padding;
DWord MediaType;};
BlockType
Constant = 0x020F
