Configuration using Web Based Management and Command Line Interface
4.5 The Switch menu
SCALANCE X-300 / X-400
Configuration Manual, 10/2014, C79000-G8976-C187-22
199
Bridge Forward Delay / Root Forward Delay
New configuration data is not used immediately by a bridge but only after the period
specified in the Forward Delay parameter. This ensures that operation is only started with
the new topology after all the bridges have the required information. The default for this
parameter is 15 seconds.
Bridge Max Age / Root Max Age
Bridge Max Age defines the maximum "age" of a received BPDU for it to be accepted as
valid by the switch. The default value for this parameter is 20.
Syntax of the Command Line Interface
Table 4- 61 Spanning Tree Configuration - CLI\SWITCH\STP>
Shows the current spanning tree configuration.
Specifies the bridge priority for the IE switch.
Specifies the interval between two BPDUs in seconds.
fwddelay [4 ... 30] Specifies the delay time for the effectiveness of configu-
ration information (specified in seconds).
Administrator only.
Default value: 15 s
maxage [6 ... 40] Maximum age for configuration information. Administrator only.
Spanning Tree Port Parameters
Port-specific parameters
This page displays the current port parameters that were either set by the user or set as a
result of the automatic functions of the IE switch.
Figure 4-85 Spanning Tree Port Parameters
The table has the following columns:
Specifies the slot and port to which the information relates.
