Siemens SINUMERIK 804D sl Function Manual

Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-247
Override
Source:
MCP setting
Destination:
Interface DB (Parameter ChanNo)
Feedrate override DB21, ... DBB4
Source:
MCP setting
Destination:
Interface DB (6 assigned axis DBs)
Feedrate override DB31, ... DBB0
Spindle override DB31, ... DBB19 (parameter SpindleIFNo)
Channel signals
Source:
MCP keys
Destination:
Interface DB (Parameter ChanNo)
NC Start DB21, ... DBX7.1
NC stop DB21, ... DBX7.3
Reset DB21, ... DBX7.7
Single block DB21, ... DBX0.4
2.12.29.3 Checkback signals from user interface for controlling displays
Operating modes and machine functions
Operating modes and machine functions
Destination:
MCP output
Source:
Interface DB (parameter ModeGroupNo)
representation for mode group 1
AUTOMATIC DB11, ... DBX6.0
MDA DB11, ... DBX6.1
JOG DB11, ... DBX6.2
REPOS DB11, ... DBX7.1
REF DB11, ... DBX7.2
TEACH IN DB11, ... DBX7.0
WCS/MCS output is operated through key actuation.
