Detailed Description
2.2 Flat D number structure
Tool Compensation (W1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-17
Define the DRF compensation in the transverse axis as a diameter compensation with:
MD20360 $MC_TOOL_PARAMETER_DEF_MASK bit 9 = 1
Deselecting an axial DRF compensation (DRFOF) also deletes an existing tool compensation
(handwheel override in tool direction).
Note
For further information about superimposed movements with the handwheel, please refer to:
References:
/FB/ Description of Functions, Extended Functions; Manual Travel and Handwheel Travel
(H1)
/PG/ Programming Guide, Fundamentals (the Programming Guide contains a complete
technical description of axis-specific deselection of the DRF compensation.)
2.2 2.2 Flat D number structure
2.2.1 General
Simple tool management
Simple tool management (no replacement tools, no magazines) using D numbers is possible
for turning machines.
The function is available in the basic level of tool management (without tool management
function activated). Grinding tools cannot be defined using this function.
Activation
Machine data:
MD18102 $MN_MM_TYPE_OF_CUTTING_EDGE
can be used to define the type of D number management that is active:
Value = 0 As previously = default setting
Value = 1 Flat D number structure with absolute direct D programming
Cutting edges can be deleted individually via PI command or NC programming command.
Cutting edges with a specific number can also be created selectively using the MMC.
