Data Lists
5.2 Signals
Auxiliary Function Output to PLC (H2)
5-4 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
DB number Byte.Bit Description
21, ... 170 - 171 Extended address of F function 3 (binary)
21, ... 172 - 175 F function 3 (real format)
21, ... 176 - 177 Extended address of F function 4 (binary)
21, ... 178 - 181 F function 4 (real format)
21, ... 182 - 183 Extended address of F function 5 (binary)
21, ... 184 - 187 F function 5 (real format)
21, ... 188 - 189 Extended address of F function 6 (binary)
21, ... 190 - 193 F function 6 (real format)
21, ... 194 Dynamic M function: M00 - M07
21, ... 195 Dynamic M function: M08 - M15
21, ... 196 Dynamic M function: M16 - M23
21, ... 197 Dynamic M function: M24 - M31
21, ... 198 Dynamic M function: M32 - M39
21, ... 199 Dynamic M function: M40 - M47
21, ... 200 Dynamic M function: M48 - M55
21, ... 201 Dynamic M function: M56 - M63
21, ... 202 Dynamic M function: M64 - M71
21, ... 203 Dynamic M function: M72 - M79
21, ... 204 Dynamic M function: M80 - M87
21, ... 205 Dynamic M function: M88 - M95
21, ... 206.0 – 206.3 Dynamic M function: M96 - M99
21, ... 318.5 Associated M00/M01 active
5.2.3 Signals to axis/spindle
DB number Byte.Bit Description
31, ... 78 - 81 F function for positioning axis (real)
