Siemens SINUMERIK 804D sl Function Manual

Data Lists
5.1 Machine data
Mode Group, Channel, Program Operation, Reset Response (K1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5-3
Number Identifier: $MC_ Description
20170 COMPRESS_BLOCK_PATH_LIMIT Maximum traversing length of NC block for
compression
20210 CUTCOM_CORNER_LIMIT Max. angle for intersection calculation with tool radius
compensation
20220 CUTCOM_MAX_DISC Maximum value with DISC
20230 CUTCOM_CURVE_INSERT_LIMIT Maximum angle for intersection calculation with tool
radius compensation
20240 CUTCOM_MAXNUM_CHECK_BLOCKS Blocks for predictive contour calculation with tool
radius compensation
20250 CUTCOM_MAXNUM_DUMMY_BLOCKS Max. no. of dummy blocks with no traversing
movements
20270 CUTTING_EDGE_DEFAULT Basic setting of tool cutting edge without programming
20400 LOOKAH_USE_VELO_NEXT_BLOCK Look Ahead to programmed following block velocity
20430 LOOKAH_NUM_OVR_POINTS Number of override switch points for Look Ahead
20440 LOOKAH_OVR_POINTS Override switch points for LookAhead
20500 CONST_VELO_MIN_TIME Minimum time with constant velocity
20600 MAX_PATH_JERK Pathrelated maximum jerk
20610 ADD_MOVE_ACCEL_RESERVE Acceleration reserve for overlaid movements
20700 REFP_NC_START_LOCK NC start disable without reference point
20750 ALLOW_GO_IN_G96 G0 logic in G96
20800 SPF_END_TO_VDI Subprogram end to PLC
21000 CIRCLE_ERROR_CONST Circle end point monitoring constant
21010 CIRCLE_ERROR_FACTOR Circle end point monitoring factor
21100 ORIENTATION_IS_EULER Angle definition for orientation programming
21110 X_AXIS_IN_OLD_X_Z_PLANE Coordinate system for automatic Frame definition
21200 LIFTFAST_DIST Traversing path for fast retraction from the contour
21210 SETINT_ASSIGN_FASTIN NCK input bytes for interrupts
21202 LIFTFAST_WITH_MIRROR Lift fast with mirror
21250 START_INDEX_R_PARAM Number of first channelspecific R parameter
5.1.2.2 Block search
Number Identifier: $MC_ Description
20128 COLLECT_TOOL_CHANGE Collect tool changes during block search
22600 SERUPRO_SPEED_MODE Velocity with block search type 5
22601 SERUPRO_SPEED_FACTOR Velocity factor for block search type 5
22621 ENABLE_START_MODE_MASK_PRT Enables MD 22620: START_MODE_MASK_ PRT for
SERUPRO search run
22622 DISABLE_PLC_START Allow part program start via PLC
22680 AUTO_IPTR_LOCK Disable interrupt pointer
