Siemens SINUMERIK 804D sl Function Manual

Data Lists
5.3 Signals
Spindles (S1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5-5
DB number Byte.Bit Description
31, ... 18.6 Direction of rotation setpoint right
31, ... 18.5 Oscillation speed
31, ... 18.4 Oscillation via PLC
31, ... 19.7 - 19.0 Spindle offset H - A
31, ... 30.4 Spindle positioning
31, ... 30.3 Select gear step
31, ... 30.2 Spindle start CCW
31, ... 30.1 Spindle start CW
31, ... 30.0 Spindle stop
31, ... 60.7 Position reached with exact stop fine
31, ... 60.6 Position reached with exact stop coarse
31, ... 60.5 Homed/synchronized 2
31, ... 60.4 Homed/synchronized 1
31, ... 60.3 Encoder limit frequency exceeded 2
31, ... 60.2 Encoder limit frequency exceeded 1
31, ... 60.0 Axis/no spindle
31, ... 61.7 Current controller active
31, ... 61.6 Speed control loop active
31, ... 61.5 Position controller active
31, ... 61.4 Axis/spindle stationary (n < n
min
)
31, ... 82.3 Change gear
31, ... 82.2-82.0 Set gear step AC
31, ... 83.7 Actual direction of rotation clockwise
31, ... 83.5 Spindle in setpoint range
31, ... 83.2 Setpoint speed increased
31, ... 83.1 Setpoint speed limited
31, ... 83.0 Speed limit exceeded
5.3.2 Signals from axis/spindle
DB number Byte.Bit Description
31, ... 84.7 Active spindle control mode
31, ... 84.6 Active spindle mode oscillation mode
31, ... 84.5 Active spindle positioning mode
31, ... 84.3 Rigid tapping active
31, ... 86 and 87 M function for spindle
31, ... 88-91 S function for spindle
