Siemens SINUMERIK 804D sl Function Manual

Data Lists
5.2 Signals
Reference Point Approach (R1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5-3
5.2 5.2 Signals
5.2.1 Signals to BAG
DB number Byte.Bit Name
11, ... 0.7 Mode group RESET
11, ... 1.2 Machine function: REF
11, ... 5.2 Active machine function: REF
5.2.2 Signals from BAG
DB number Byte.Bit Name
11, ... 5.2 Active machine function REF
5.2.3 Signals to channel
DB number Byte.Bit Name
21, ... 1.0 Activate referencing
21, ... 28.7 OEM channel signal (MMC → PLC) REF
5.2.4 Signals from channel
DB number Byte.Bit Name
21, ... 33.0 Referencing active
21, ... 35.7 Reset
21, ... 36.2 All axes referenced
