Tool Compensation (W1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5-1
Data Lists
5
5.1 5.1 Machine data
5.1.1 NC-specific machine data
Number Identifier: $MN_ Description
18082 MM_NUM_TOOL Number of tools that the NCK can manage (SRAM)
18088 MM_NUM_TOOL_CARRIER Number of toolholders
18094 MM_NUM_CC_TDA_PARAM Number of TOA data
18096 MM_NUM_CC_TOA_PARAM Number of TOA data, which can be set up per tool
and evaluated by the CC
18100 MM_NUM_CUTTING_EDGES_IN_TOA Tool compensations per TOA module
18102 MM_TYPE_OF_CUTTING_EDGE Activate flat D number management
18105 MM_MAX_CUTTING_EDGE_NO Address extension interpreted as spindle number
18106 MM_MAX_CUTTING_EDGE_PERTOOL Maximum number of cutting edges per tool
18108 MM_NUM_SUMCORR Number of all sum offsets in NCK
18110 MM_MAX_SUMCORR_PER_CUTTEDGE Maximum number of sum offsets per cutting edge
18112 MM_KIND_OF_SUMCORR Properties of sum offsets in the NCK
18114 MM_ENABLE_TOOL_ORIENT Assign orientation to cutting edges
18116 MM_NUM_TOOL_ENV Tool environments in TO area
