Siemens SINUMERIK 804D sl Function Manual

Diagnostic Tools (D1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5-1
Data Lists
5
5.1 5.1 Machine data
5.1.1 NC-specific machine data
Number Identifier: $MN_ Description
11410 SUPPRESS_ALARM_MASK Mask for suppressing special alarms
11411 ENABLE_ALARM_MASK Activation of special alarms
11412 ALARM_REACTION_CHAN_NOREADY Alarm reaction CHAN_NOREADY permitted
11413 ALARM_PAR_DISPLAY_TEXT Texts as alarm parameters (Siemens Rights)
11420 LEN_PROTOCOL_FILEX File size for protocol files (KB)
13030 DRIVE_MODULE_TYPE Module identifier (SIMODRIVE 611 digital)
5.1.2 Axis/spindle-specific machine data
Number Identifier: $MA_ Description
32200 POSCTRL_GAIN [n] Servo gain factor
32250 RATED_OUTVAL Rated output voltage
32260 RATED_VELO Rated motor speed
36010 STOP_LIMIT_FINE Exact stop fine
36030 STANDSTILL_POS_TOL Zero speed tolerance
36050 CLAMP_POS_TOL Clamping tolerance
36210 CTRLOUT_LIMIT Maximum speed setpoint
36300 ENC_FREQ_LIMIT[n] Encoder limit frequency
36400 CONTOUR_TOL Tolerance band contour monitoring
36500 ENC_CHANGE_TOL Max. tolerance for actual position value acquisition
37010 FIXED_STOP_TORQUE_DEF Clamping torque
43510 FIXED_STOP_TORQUE Fixed stop clamping torque
