Siemens SINUMERIK 804D sl Function Manual

Data Lists
5.3 Signals
Various NC/PLC Interface Signals and Functions (A2)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5-7
5.3.6 Signals from axis/spindle
DB number Byte.Bit Description
31, ... 60.4 / 60.5 Referenced, synchronized 1 / Referenced, synchronized 2
31, ... 61.3 Follow-up mode active
31, ... 64.6 / 64.7 Traverse command minus / plus
31, ... 61.3 Follow-up mode active
31, ... 61.4 Axis/spindle stops
31, ... 61.5 Position controller active
31, ... 61.6 Speed control loop active
31, ... 61.7 Current controller active
31, ... 1, 2 Parameter set switchover (feedback)
31, ... 76.0 Lubrication pulse
31, ... 92.0 Setup mode active
31, ... 92.1 Rampfunction-generator fast stop active
31, ... 92.2 Torque limit 2 active
31, ... 92.3 Speed setpoint smoothing active
31, ... 93.2 Active drive parameter set A, B, C
31, ... 93.4 Active motor A, B
31, ... 93.5 Drive Ready
31, ... 93.6 Speed controller integrator disabled
31, ... 93.7 Pulses enabled
31, ... 94.0 Motor temperature prewarning
31, ... 94.1 Heat-sink temperature prewarning
31, ... 94.2 Ramp-up function completed
31, ... 94.3 |M
d
| < M
dx
31, ... 94.4 |n
act
| < n
min
31, ... 94.5 |n
act
| < n
x
31, ... 94.6 n
act
= n
set
31, ... 94.7 Variable signaling function
31, ... 95.0 U
DC link
<warning threshold
