Tool Compensation (W1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
1-1
Brief Description
1
Calculating tool compensation data
The SINUMERIK 840D/810D controls can be used to calculate the following tool
compensation data:
• Length compensation
• Radius compensation
• Storage of tool data in a flexible tool compensation memory:
– Tool identification with T numbers from 0 to 32000
– Definition of a tool with a maximum of 9 cutting edges
– Cutting edge described by up to 25 tool parameters
Type
Geometry: Length Wear: Length Base/adapter dimension
Geometry: Radius Wear: Radius
Technology
• Tool selection selectable: Immediate or via selectable M function
• Tool radius compensation:
– Selection and deselection strategy configurable: Normal or contour-related
– Compensation active for all interpolation types:
Linear
Circle
Helical
Spline
Polynomial
Involute
– Compensation at outside corners selectable:
transition circle/ellipse (G450) or equidistant intersection (G451)
– Parameter-driven adaptation of G450/G451 functions to the contour
– Free traversing on outer corners with G450 and DISC parameter
– Number of dummy blocks without axis motion selectable in the compensation plane
