Siemens SINUMERIK 804D sl Function Manual

Data Lists
5.3 Signals
Feeds (V1)
5-4 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5.3 5.3 Signals
5.3.1 Signals to channel
DB number Byte.Bit Description
21, ... 0.6 Activate dry run feed
21, ... 4 Feed override
21, ... 5 Rapid traverse override
21, ... 6.0 Feed disable
21, ... 6.6 Rapid traverse override active
21, ... 6.7 Feed override active
21, ... 12.3 Feed stop, geometry axis 1
21, ... 16.3 Feed stop, geometry axis 2
21, ... 20.3 Feed stop, geometry axis 3
5.3.2 Signals from channel
DB number Byte.Bit Description
21, ... 24.6 Dry run feed selected
21, ... 25.3 Feed override for rapid traverse selected
21, ... 29.0
29.1
29.2
29.3
Activate fixed feedrate 1 for path/geometry axes
Activate fixed feedrate 2 for path/geometry axes
Activate fixed feedrate 3 for path/geometry axes
Activate fixed feedrate 4 for path/geometry axes
