Detailed Description
2.2 Service displays
Diagnostic Tools (D1)
2-4 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Alarm display control
The scope of the alarm outputs can be modified using machine data.
• MD11410 $MN_SUPPRESS_ALARM_MASK
Mask for suppressing special alarm outputs
• MD11411 $MN_ENABLE_ALARM_MASK
Mask for enabling special alarm outputs
For details of this machine data, please refer to chapter 4.
2.2 2.2 Service displays
Conditions of use
Conditions for the use of service displays are specified. Service displays are differentiated
between in terms of axis/spindle, drive and profibus DP
Operation
For how to operate the service displays see:
References: /BAD/, "HMI Advanced Operator's Guide"
/BEM/, "HMI Embedded Operator's Guide"
Note
On HMI Advanced, it is possible to switch between the displays using the vertical soft key for
Part view/Overall view. The data in the partial view are updated at significantly shorter
intervals.
General
In principle, the following service displays are available:
• Axis/spindle service displays
• Drive service displays
• Profibus-DP service displays
