Detailed Description
2.9 Program control
Mode Group, Channel, Program Operation, Reset Response (K1)
2-122 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Table 2-10 Program control: Interface signals
Function Selection signal Activation signal Feedback signal
SKP skip block 0 to 7
SKP skip block 8 to 9
DB21, ... DBX26.0- 26.7
DB21, ... DBX27.0- 27.1
DB21, ... DBX2.0- 2.7
DB21, ... DBX31.6- 31.7
- - -
DRY dry run feedrate DB21, ... DBX24.6 DB21, ... DBX0.6 DB21, ... DBX318.6
ROV Rapid traverse override DB21, ... DBX25.3 DB21, ... DBX6.6 - - -
Single block: Preselection of SBL1, SBL2 or SBL3 via program control display of HMI
SBL1: Action single block
SBL2: Decoding single block
SBL3: In cycle
HMI operator panel DB21, ... DBX0.4 - - -
M01 (Programmed stop) DB21, ... DBX24.5 DB21, ... DBX0.5 DB21, ... DBX32.5
Associated M01 DB21, ... DBX24.4 DB21, ... DBX30.5 DB21, ... DBX318.5
DRF selection DB21, ... DBX24.3 DB21, ... DBX0.3 DB21, ... DBX33.3
PRT program test DB21, ... DBX25.7 DB21, ... DBX1.7 DB21, ... DBX33.7
References:
/LIS/ Lists "Interface Signals"
/BAD/ Operator's Guide "Machine Operating Area"
2.9.2 Activation of skip levels
/, /0, ... /9
It is possible to skip blocks, which are not to be executed every time the program runs. The
blocks to be skipped are always identified by a slash character ("/") in front of the block
number.
The skip levels are specified in the part program with "/0" to "/7".
Only one skip level can be specified per part program block.
Number of levels
MD9423 $MM_MAX_SKP_LEVEL is used to define the number of skip levels.
