Detailed Description
2.9 Mode group, channel, program operation, reset response (K1)
NC/PLC Interface Signals (Z1)
2-110 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2.9.5 Signals to axis/spindle (DB31, ...)
DB31, ...
DBX10.0
REPOSDELAY
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The REPOS offset of the axis is first applied with its next programming.
Signal state 0 or
edge change
1 → 0
There is no REPOS offset.
Special cases,
errors, ......
The signal is not relevant for path axes.
Corresponds to .... DB21, ... DBX31.0 - DBX31.2 (REPOSPATHMODE0-2)
DB31, ... DBX70.2 (REPOS Delay Ackn)
DB31, ... DBX72.0 (REPOSDELAY)
2.9.6 Signals from axis/spindle (DB31, ...)
DB31, ...
DBX70.0
REPOS offset
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
A REPOS offset must be applied for the appropriate axis.
Signal state 0 or
edge change
1 → 0
No REPOS offset need be applied for the appropriate axis.
Corresponds to .... DB31, ... DBX70.1 (REPOS offset valid)
