Various NC/PLC Interface Signals and Functions (A2)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5-1
Data Lists
5
5.1 5.1 Machine data
5.1.1 Memory specific machine data
Number Identifier: $MM_ Description
HMI
Advanced
HMI
Embedded
9000 9000 LCD_CONTRAST Contrast
9001 9001 DISPLAY_TYPE Monitor type
9002 DISPLAY_MODE External monitor (1: black and white, 2: color)
9003 FIRST_LANGUAGE Foreground language
9004 9004 DISPLAY_RESOLUTION Display resolution
9005 PRG_DEFAULT_DIR Basic setting Program directory
9006 DISPLAY_BLACK_TIME Time setting for screen saver
9007 TABULATOR_SIZE Tabulator length
9008 9008 KEYBOARD_TYPE Keyboard type (0: OP, 1: MFII/QWERTY)
9009 9009 KEYBOARD_STATE Shift behavior of keyboard during booting
9010 SPIND_DISPLAY_RESOLUTION Display resolution for spindle values
9011 9011 DISPLAY_RESOLUTION_INCH Display resolution for INCH_system of units
9012 9012 ACTION_LOG_MODE Set action mode for action log
9013 SYS_CLOCK_SYNC_TIME System clock synchronizing time
9020 9020 TECHNOLOGY Basic configuration for simulation and free
contour programming
9030 EXPONENT_LIMIT Number of places to be displayed without
exponent
9031 EXPONENT_SCIENCE Technical exponent representation in three
steps
9180 USER_CLASS_READ_TCARR Protection level read tool carrier offsets
general
9181 USER_CLASS_WRITE_TCARR Protection level write tool carrier offsets
general
9200 9200 USER_CLASS_READ_TOA Protection level read tool offsets general
9201 9201 USER_CLASS_WRITE_TOA_GEO Protection level write tool geometry
