Detailed Description
2.5 Toolholder with orientation capability
Tool Compensation (W1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-105
This number of toolholder data sets, divided by the number of active channels, can be
defined for a channel.
Exception:
If non-standard settings are selected via machine data:
MD28085 $MC_MM_LINK_TOA_UNIT.
Canceling all toolholder data blocks
All values of all toolholder data sets can be deleted from within the part program using one
command.
$TC_CARR1[0] = 0
Values not set by the user are preset to 0.
Activation
A toolholder becomes active when both a toolholder and a tool have been activated. The
selection of the toolholder alone has no effect. The effect of selecting a toolholder depends
on the G code TCOABS/TCOFR (modal G-code group for toolholders).
Changing the G code in the TCOABS/TCOFR group causes recalculation of the tool length
components when the toolholder is active. With TCOABS, the values stored in the toolholder
data for both angles of rotation α1and α2 are used to determine the tool orientation.
With TCOFR, the two angles are determined from the current frame. The values stored in the
toolholder data are not changed, however. These are also used to resolve the ambiguity that
can result when the angle of rotation is calculated from one frame. Here, the angle that
deviates least from the programmed angle is selected from the various possible angles.
Note
For more information about programming tool compensations with toolholder kinematics and
system variables, please refer to:
References:
/PGA/ Programming Guide, Production Planning.
2.5.7 Supplementary conditions and control system response for orientation
Full orientation
For a given data set that describes a certain kinematic, all the conceivable special
orientations can only be displayed when the following conditions are satisfied:
