Siemens SINUMERIK 804D sl Function Manual

Data Lists
5.1 Machine data
Spindles (S1)
5-2 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5.1.3 Axis/spindle-specific machine data
Number Identifier: $MA_ Description
30300 IS_ROT_AX Rotary axis
30310 ROT_IS_MODULO Modulo conversion
31044 ENC_IS_DIRECT2 Encoder on intermediate gear
31050 DRIVE_AX_RATIO_DENOM Denominator load gearbox
31060 DRIVE_AX_RATIO_NUMERA Numerator load gearbox
31064 DRIVE_AX_RATIO2_DENOM Intermediate gear denominator
31066 DRIVE_AX_RATIO2_NUMERA Intermediate gear numerator
31070 DRIVE_ENC_RATIO_DENOM Measuring gear denominator
31080 DRIVE_ENC_RATIO_NUMERA Measuring gear numerator
31122 BERO_DELAY_TIME_PLUS BERO delay time in plus direction
31123 BERO_DELAY_TIME_MINUS BERO delay time in minus direction
32200 POSCTRL_GAIN K
V
factor
32800 EQUIV_CURRCTRL_TIME Equivalent time constant current control circuit for
feedforward control
32810 EQUIV_SPEEDCTRL_TIME Equivalent time constant speed control circuit for
feedforward control
32910 DYN_MATCH_TIME Time constant for dynamic matching
34040 REFP_VELO_SEARCH_MARKER Reference point creep speed
34060 REFP_MAX_MARKER_DIST Monitoring of zero mark distance
34080 REFP_MOVE_DIST Reference point distance/destination point for
distancecoded system
34090 REFP_MOVE_DIST_CORR Reference point offset/absolute offset, distance-coded
34100 REFP_SET_POS Reference point value
34200 ENC_REFP_MODE Homing mode
35000 SPIND_ASSIGN_TO_MACHAX Assignment of spindle to machine axis
35010 GEAR_STEP_CHANGE_ENABLE Gear step change options
expandable at fixed position
35012 GEAR_STEP_CHANGE_POSITION Gear step change position
35020 SPIND_DEFAULT_MODE Basic spindle setting
35030 SPIND_DEFAULT_ACT_MASK Activate initial spindle setting
35035 SPIND_FUNCTION_MASK Setting of spindle-specific functions
35040 SPIND_ACTIVE_AFTER_RESET Spindle active after reset
35100 SPIND_VELO_LIMIT Maximum spindle speed
35110 GEAR_STEP_MAX_VELO[n] Maximum speed for gear change
35120 GEAR_STEP_MIN_VELO[n] Minimum speed for gear change
35130 GEAR_STEP_MAX_VELO_LIMIT[n] Maximum speed of gear step
35140 GEAR_STEP_MIN_VELO_LIMIT[n] Minimum speed of gear step
