Siemens SINUMERIK 804D sl Function Manual

Detailed Description
2.9 Mode group, channel, program operation, reset response (K1)
NC/PLC Interface Signals (Z1)
2-86 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
DB11, ...
DBX4.1 Selected mode MDA
Edge evaluation: Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
MDA mode is selected by the MMC.
Signal state 0 or
edge change
1 → 0
MDA mode is not selected by the MMC.
DB11, ...
DBX4.2
Data block
Selected JOG mode
Signal(s) from the mode group (MMC → PLC)
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
JOG mode is selected by the MMC.
Signal state 0 or
edge change
1 → 0
JOG mode is not selected by the MMC.
DB11, ...
DBX5.0 Selected machine function TEACH IN
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
Machine function TEACH IN is selected in the mode group by the MMC.
Signal state 0 or
edge change
1 → 0
Machine function TEACH IN is not selected by the MMC.
Additional references /BA/ Operator's Guide
