107
Transition Preview
In transition preview mode, the status during a transition
is output on the preview output of the switcher bank.
You can check the change in the i
mage due to a transition
in advance using a monitor configured for the preview
output.
• In the simple-type transition control block, transition
p
review cannot be configured or executed.
• It is not possible to execute a
transition preview in the
following cases.
– Transition in progress
– When bus fixed mode is set
– When the switcher bank operation mode is not
stan
dard mode
• The buttons used for configuring and executing a
transit
ion preview must be assigned to the transition
control block beforehand.
For details about assign
ing buttons, see “Assigning
Control Panel Buttons” (page 397).
Setting Transition Preview
There are two modes for a transition preview.
Normal:
Set the [TRANS PVW] button
operation mode to
hold mode or lock mode.
In hold mode, the transition pr
eview mode is enabled
only while the [TRANS PVW] button is pressed.
In lock mode, pressing the
[TRANS PVW] button
switches between setting and releasing transition
preview mode each time the button is pressed.
For details about setting lock
mode/hold mode, see
“Setting the operation mode of the [TRANS PVW]
button in the transition control block” (page 413).
One-time:
Pressing the [TRANS PVW] button switches to
tr
ansition preview mode, and then transition preview
mode is released when the transition is completed.
For details about setting normal mode/one-time mode,
see “Setting the Transition Prev
iew Mode” (page 390).
Executing Transition Preview
1
Press the [TRANS PVW] button, turning it on, in the
transition control block.
The [TRANS PVW] button is lit green, and the
swi
tcher enters transition preview mode.
The current program output is displayed on the
p
review output monitor.
2
Execute a transition.
The status during the transition is displayed on the
p
review output monitor allowing you to check the
changes to the image.
Notes
To Next Page
