Chapter
174
Clip Transitions
Overview
You can play frame memory video content linked to a
background transition, such as a mix or wipe.
A key for a clip transition is mixed with the background
du
ring execution of the transition.
Clip transition restrictions
• Pattern limits cannot be used.
• Transition preview cannot be used.
• It is not possible to set the transiti
on rate of a clip
transition.
• A clip transition cannot be saved in an effect timeline as
a keyfra
me.
• The state of a clip transition d
uring execution cannot be
saved in a snapshot.
• When recalling a snapshot that includes a clip transition
whi
le executing another clip transition, the subsequent
transition does not operate properly. Recall the
snapshot after the transition completes.
• When recalling a DME wipe snapshot while executing
a
clip transition, the image may be distorted.
• Transitions executed in two stroke
s, such as a preset
color mix when the stroke mode is set to normal mode,
or a DME wipe with a picture-in-picture pattern, will
not execute properly.
• When a clip transition is sele
cted, the wipe direction
selection button in the transition control block/
transition control block (simple type) that is lit indicates
the playback direction of the frame memory clip.
Setting a Clip Transition
This section describes clip transitions using frame
memory output channels 1 and 2 on M/E-1 as an example.
Selecting a Transition Type
You can select a clip transition on a frame memory output
channel to use using the transition control block,
transition control block (simple type), or the menu.
To select using the transition control block
Press a [FM1&FM2 CLIP] to [FM15&FM16 CLIP]
bu
tton, turning it on, in the transition control block/
transition control block (simple type).
For frame memory output channels 1 and 2, press the
[FM1&FM2 CLI
P] button, turning it on.
For details, see “Setting a transition type (transition
control block)” (page 98).
When the system signal format is 2160P, only the
[FM1&FM2 CLI
P] button, [FM3&FM4 CLIP] button,
and [FM5&FM6 CLIP] button can be selected.
To select using the menu
In the Home > M/E-1 > Bus/Transit
ion > Transition >
Transition Type menu (11109.21), set a [FM 1&2 Clip] to
[FM 15&16 Clip] button in the [Transition Type] group
to the on state.
For frame memory outp
ut channels 1 and 2, set the [FM
1&2 Clip] button to the on state.
For details, see “Setting the key transition type (menu)”
(page 98).
When the system signal format is 2160P, only the [FM
1
&2 Clip] button, [FM 3&4 Clip] button, and [FM 5&6
Clip] button can be selected.
Note
Note
