466
Number of Switcher
Resources
The number of resources that can be used will vary
depending on the system signal format.
The maximum number of resources for
4K format
(2160P) and HD format (1080P, 1080i, 720P) are shown
below.
To use 4K formats, the XZS-G1500 4K Upgrade License
is requi
red.
a) You can change the switcher bank (M/E-1 to M/E-5, P/P) assignment in
the Home > Setup > Switcher > Config > M/E Assign menu (19103.11).
b) If the number of keys on a single switcher bank is four or lower, SL keys
can be used.
c) When the system signal format is
720P, a format converter cannot be
used.
d) To use the HDR converter function, the XZS-G1750 HDR Converter
L
icense is required.
e) To use the DME function, the XKS-
G1600 GPU Pack and XZS-G1610
3D DME License are required.
For 4K formats, either DMEs or SL keys can be enabled.
f) To use the clip player function,
the XKS-G1600 GPU Pack and
XZS-G1800 Clip Player License are required.
SL Key Restrictions
If the number of keys on a single switcher bank is four or
lower, SL keys are set as key 5 to key 8.
Only one switcher bank can use an SL key.
To use the SL key function, the following options are
requir
ed.
• XKS-G1600 GPU Pack
• XZS-G1620 SL Key License
When the system signal format is 2160P, the SL key
fu
nction must be enabled for use.
For details about setting GPU functions, see “Setting a
GPU” (page 364).
Restrictions
Setting keys
• Only Linear key type supported
However, the following settings are not supported.
– [Filter] parameter
–Clean mode
–Key invert
– Key position
• Key edge not supported
• Mask not supported
• Blink not supported
• Processed Key not supported
• Video Process supported
However, the following settings are not supported.
– [Hue Delay] parameter
– [Black Level] parameter
• For resizer, only two-dimensional transform movement
([Location X]
parameter, [Location Y] parameter)
supported
• Use of still image combined content for key fill/key
source
– Selecting a signal using cross-po
int buttons not
supported
– Color matte setting for key fill not supported
– Selecting self mode/auto sele
ct mode/split mode for
key source not supported
• Key Priority supported
However, the following restriction
s apply.
– SL keys (key 5 to key 8) assigned the priority of four
k
eys as a single group
– Within SL keys (key 5 to key 8), arbitrary priority
su
pported
Transitions
• Configurable for mix and cut transition types only
• Transition preview not supported
• Key priority change not supported, depending on the
t
ransition
Note
Resource 4K HD
Switcher banks
a)
1 2
When M/E split is enabled 2 4
Keys
b)
4 16
Keys per switcher bank 4 8
Inputs 24 44
Inputs configurable with a format
converter
c)
12 24
Inputs configurable with a color corrector/
HDR
converter
d)
6 –
Outputs 12 24
Outputs configurable with a format
converter
c)
6 12
Outputs configurable with a color
corrector/HDR converter
d)
3 –
DME channels
e)
2 4
DME channel 1 when enhanced function
mod
e is enabled
1 3
DME channels 1 and 2 when enhanced
function
mode is enabled
– 2
Frame memory output channels 6 16
Clip player output channels
f)
2 4
Multi viewers 1 2
Color backgrounds 1 2
