Transition type
You can set the way in which the transition occurs.
You can select the following transition types.
Basic Operation for
Transitions
The basic transition operation flow is as follows.
1
Select a background image using the background A
bus cross-point buttons in the cross-point control
block.
2
Select the switch target of a transition.
Select a next transition u
sing the next transition
selection buttons in the transition control block.
For details about next transitions, see “Next
Transitions” (page 95).
3
Set the state for after the transition executes.
When switching the background, se
lect a background
image using the background B bus cross-point
buttons.
For details about select
ing a signal, see “Chapter 4
Selecting Signals” (page 80).
When inserting a key, set the key to insert.
For details about setting keys, see “Chapter 6 Keys”
(page 115).
When changing the key overla
y sequence, set the key
priority.
For details about key priority, see “Key Priority”
(page 96).
4
Select a transition type.
Select a transition type usi
ng the transition type
selection buttons in the transition control block.
To switch (cut) from the current image
in
stantaneously to the new image, proceed to step
6
.
For details about transition types, see “Transition
Type” (page 98).
5
Set the transition type.
Make the required settings for the selected transition
type.
• Transition rate settings (see page 100)
• Super mix settings (see page 99)
• Preset color mix settings (see page 99)
• Wipe settings (see page 149)
• DME wipe settings (see page 166)
• Clip transition settings (see page 174)
Using transition preview mode, you can check the
exe
cution of the transition.
Transition type Description
Mix The new image progressively
fades in ove
r the current image.
The sum of the two image outputs
is maintained constant, and the
output of each is at 50% at the
mid-point of the transition.
NAM (non-additive
mix)
The current image and new image
are
compared, and the image with
the higher luminance level is given
priority in the output. The output of
each is at 100% at the mid-point of
the transition.
Super mix The current image output is held at
100%, and is mixed with the new
image. The output at the mid-point
of the transition can be 0% to
100%.
Preset color mix A color matte (plain image) is
inse
rted during the transition,
where the current image is
switched to the new image in a
two-stage transition.
Wipe The current image switches to the
new
image using a wipe pattern.
DME wipe The current image switches to the
new
image using a DME wipe
pattern.
Clip transition Plays back frame memory video
conten
t linked to a mix or wipe
transition.
Cut The current image switches
instan
taneously to the new image.
